Bar Joist Attachment - DBA
Designed for use in both lateral and longitu- dinal seismic bracing applications.
• The connecting accessory used is DSA.
• The installation torque of the bolt is 50–65 N·m.
• After gripping the H-steel, tighten the shear bolt until the head breaks off.
• The maximum thickness of the H-steel is 16 mm.
• Material : Ductile iron
• Coating : Zinc Plated
• Approval : FM Approved
• Designed for use in both lateral and longitu- dinal seismic bracing applications.
• Can be mounted to bar joists or angle iron.
• Spring retainer provides easy positioning.
• Snap-off bolt head allows for easy installati- on and inspection of seismic braces.
• No field assembly required.
• Must be installed in accordance with NFPA 13 standards and installation instructions.
| Kod Code |
Destek Elemanı Brace Member |
Flanş Kalınlığı Flange (FT) |
Vida Çapı Screw Size |
A (mm) |
B (mm) |
C (mm) |
|||
| 37000DSA10 | 1" SCH40 Boru / Pipe | 18 | 1/2" | 80 | 54 | 75 | |||
